Pseudo-Natural Product Annotation

Pseudo-Natural Products (PNP) are defined as synthetic compounds, containing Natural Product (NP) fragments arrangments not found in the Nature.

To determine whether a compound is a PNP or not (in which case it is NP-like), its Fragment Combinatio Graph (FCG) is compared with all FCGs from the Natural Dataset. A match is found when the whole synthetic FCG is included in any natural FCG.

_images/pnp_example.png

For molecules whose fragment connectivity can be explained by several different FCGs (see here), every FCG is individually compared to each natural FCG. If a molecule has at least 1 FCG with matches, then the molecule is described as NP-like.

Usage

To identify PNPs in a dataframe with FCGs, use the following command:

>>> from npfc import load
>>> from npfc import fragment_combination_graph
>>> df_fcg = load.file('fcg.csv.gz')  # dataframe with FCGs to probe
>>> df_fcg = load.file('fcg_nat.csv.gz')  # dataframe with ref natural FCGs
>>> # Annotate PNPs, by default, consider edge annotations,
>>> # such as fragment- combination types (fcc) and combinaton points (fcp_1, fcp_2)
>>> df_pnp = fragment_combination_graph.annotate_pnp(df_fcg, df_fcg_nat)
>>> # It is possible to consider only the combination type:
>>> df_pnp = fragment_combination_graph.annotate_pnp(df_fcg, df_fcg_nat, data=['fcc'])
